WIN A: Pixfra MILE 2 M215M Handheld Thermal Monocular - (Manual Focus) - 256x192/12µm/15mm 35mk
#505
#502
#503
#504
#501
Designed for versatility, the M215M features manual focus control, allowing users to fine-tune their view for maximum clarity. The monocular boasts a sharp 800×600 OLED display, which presents thermal images in vivid detail, making it ideal for prolonged observation without straining the eyes. With a slimline, ergonomic design, the device remains lightweight and portable, easily fitting into your pocket or backpack for convenient transportation. The inclusion of a soft pouch, neck strap, and wrist strap further enhances comfort and usability, ensuring that the monocular remains secure and easy to access at all times.
The Pixfra Mile 2 M215M is built to perform in all weather conditions. Its IP67 rating provides dust and water resistance, ensuring the device continues to operate in challenging environments such as heavy rain, fog, and extreme temperatures ranging from -30°C to +55°C. This ruggedness makes it a reliable companion for outdoor professionals and adventurers. Additionally, the monocular’s long-life rechargeable lithium battery offers up to 8.5 hours of continuous use on a single charge, allowing users to stay engaged with their observations throughout the day and into the night.
One of the standout features of the Mile 2 M215M is its seamless connectivity. Equipped with built-in Wi-Fi, it can easily pair with up to four smart devices, allowing for group observations and live viewing through the free Pixfra app, compatible with both Android and iOS devices. The range of connectivity extends up to 40 meters, offering added flexibility for shared viewing experiences. Furthermore, the monocular supports video recording and still image capture, giving users the ability to document their observations for later review. With onboard storage of 16GB, you can easily store and access your recordings and images, ensuring that no detail is missed.
Whether you're looking for a reliable tool for surveillance, wildlife observation, or any other outdoor activity, the Pixfra Mile 2 M215M Handheld Thermal Monocular combines powerful performance, ease of use, and a robust design, making it an indispensable tool for professionals and enthusiasts alike.
| Product Name A-Z | WIN A: Pixfra MILE 2 M215M Handheld Thermal Monocular - (Manual Focus) - 256x192/12µm/15mm 35mk |
|---|---|
| SKU | OPTICSDRAWS#512 |
Specs
- Thermal Sensor: 256×192, 12μm, <35mK NETD
- Objective Lens: 15mm f1.0
- Spectral Range: 8 μm – 14 μm
- Field of View: Horizontal: 11.7°, Vertical: 8.8°, @100m: H: 20.5m, V: 15.4m
- Focus Control: Manual
- Close Focus Distance: 2.6m (8.53 ft)
- Detection Range: Up to 800m
- Magnification: 2.33x
- Frame Rate: 50 Hz
- Display: 800×600, 0.32” OLED
- Color Palettes: 6 (White Hot, Black Hot, Iron Red, Alarm, Emerald, Amber)
- Video Compression: H.264
- Diopter: –3 D to +1 D
- Eye Relief: 13mm (0.51”)
- Exit Pupil: 5mm (0.20”)
- Digital Zoom: 1x, 2x, 4x, 8x
- Video Recording: Yes
- Still Image Capture: Yes
- Wi-Fi Hotspot: Yes
- Hot Spot Tracking: Yes
- Video Distance Measurement: Yes
- FFC Calibration: Auto, Manual, External Correction
- Standby Mode: Yes
- DPC (Defective Pixel Correction): Yes
- Storage: Built-in 16GB
- Battery Type: Rechargeable Lithium Battery
- Battery Life: 8.5 hours (@ 25°C)
- Power Supply: 5 VDC/2 A
- Port: USB Type-C
- Overvoltage Protection: Yes
- Operating Temperature: –30 to +55°C (–22 to +131°F)
- Operating Humidity: ≤95%
- Protection Grade: IP67 (Dust and Water Resistant)
- Product Dimensions: 155.3mm x 56.6mm x 50.3mm (6.12” x 2.23” x 1.98”)
- Gross Weight: 760g (1.68 lb)
- Net Weight: 270g (0.60 lb)
Features
-
High-Resolution Thermal Imaging: Offers clear detection of heat signatures up to 800 meters with a 256×192 thermal sensor, enabling precise observation even in low-visibility conditions.
-
Manual Focus Control: Provides the user with the ability to manually adjust focus for optimal image clarity, ensuring that distant or small heat sources are sharply defined.
-
OLED Display: Features an 800×600 OLED screen that delivers vivid, high-contrast thermal imagery, making it easier to identify and track targets over extended periods.
-
Wi-Fi Connectivity: Equipped with built-in Wi-Fi, allowing users to connect the monocular to up to four smart devices simultaneously, facilitating group observations and live viewing through the Pixfra app (compatible with both Android and iOS).
-
Live Sharing Capability: With Wi-Fi connectivity, users can share live thermal images with multiple devices up to a range of 40 meters, perfect for collaborative fieldwork or team-based activities.
-
Rugged and Weather-Resistant: The IP67 rating protects the monocular from dust and water, ensuring reliable performance in tough conditions like rain, fog, or extreme temperatures.
-
Long Battery Life: Features a rechargeable lithium battery that provides up to 8.5 hours of continuous use, allowing for prolonged observations during both day and night.
-
Built-In Video Recording: Capable of recording both video and still images, allowing users to document and review their observations for later analysis.
-
16GB Storage: Includes 16GB of internal storage for saving videos, images, and other data captured during use.
-
Compact and Lightweight Design: Its slimline, ergonomic construction makes it easy to handle and transport, fitting comfortably in a pocket or bag.
-
User-Friendly Interface: The design reduces the number of physical buttons by integrating the power button into the Pixfra logo, simplifying navigation and enhancing ease of use.
-
Temperature Resistance: Operates effectively in temperatures ranging from -30°C to +55°C, ensuring reliability in a wide range of environmental conditions.
-
Included Accessories: Comes with a soft pouch, neck strap, and wrist strap, ensuring that the monocular stays secure and is easy to carry.
-
DPC (Defective Pixel Correction): Features automatic and manual options for correcting any defective pixels, maintaining the quality of thermal imaging.
In the box?
- Pixfra MILE 2 M215M Handheld Thermal Monocular - (Manual Focus) - 256x192/12µm/15mm 35mk
- USB Type-C Charging Cable
- Wristband
- Lanyard
- Lens Cloth
- Camera Pouch
- Eyeshade
- Quick Start Guide
Warranty
- Pixfra 3 year warranty
